EarthQuaker Devices Stereo Easy Listening

Stereo Easy Listening – Analog Amp Simulator

Stereo Easy Listening® is a compact, meticulously voiced stereo analog amp simulatorwith zero latency and no harsh digital artifacts. It can be used as a standalone analog alternative to digital modeling or to add analog character to a digital modeling setup. It is suitable for recording, practice and direct connection to a PA system.

Active Three-Band EQ

The foundational sound is inspired by the warm, mid-scooped character of a classic American amplifier. The active three-band EQ with dedicated Bass, Middle and Treblecontrols allows a wide range of tones to be shaped.

Flexible Routing

Two ¼" inputs provide stereo connectivity, while dual XLR outputs can send the signal tofront-of-house or a DAW. The signal can also be sent directly to headphones. When running mono, connecting to the Left input automatically converts the signal to stereo.

Aux Input

The dedicated Aux input features its own level control and bypasses the preamp and cabinet simulator circuitry. It can be used to play along with music from a phone throughheadphones or to connect drum machines and backing tracks while controlling the mixfrom the stage.

Controls

Level: Master volume control.
Aux: Volume control for the Auxiliary input. The Auxiliary input bypasses the preamp and cabinet simulator circuitry.
Bass: Cuts and boosts frequencies up to 500 Hz.
Middle: Cuts and boosts frequencies from 500 Hz to 2 kHz.
Treble: Cuts and boosts frequencies from 2 kHz and up.

Specifications

Dimensions: 127 x 70 x 64 mm, including knobs
Current Draw: 200 mA
Input Impedance: 1 MΩ
Headphone Output Impedance: 10 Ω
XLR Output Impedance: 100 Ω
Power: Standard 9 V DC power supply with a 2.1 mm negative center barrel.
Power Supply Recommendation: Pedal-specific, transformer-isolated wall-wart power supplies or multiple isolated-output supplies are recommended.
Warning: Do not run at higher voltages.
