Yamaha DXS18 Black MK3

The DXS18 mk3 is the largest model of Yamaha’s latest generation of DXS series powered subwoofers. The new model delivers deep, clear, and remarkably powerful, ultra-low bass thanks to our proprietary high-durability transducers, redesigned high-efficiency power amplifiers, and an ideal bandpass structure that eliminates unwanted cabinet noise. When paired with our perfectly matched DXR mk3 series loudspeakers in particular, the DXS18 mk3 enables users to build a seamlessly integrated sound system with unparalleled impact.

18" Cone, 4" Voice coil proprietary high-durability speaker unit
Newly developed 2500 W Class-D amplifier
High-output woofer with an ideal bandpass cabinet design for superior bass response, delivering a maximum 134 dB SPL
Built-in D-XSUB processing allows you to extend the frequency response even lower, up to 32 Hz
Extremely flexible X-OVER settings with DSP
Cardioid mode for bass management onstage
Plywood cabinet is durable and acoustically optimized for maximum sound quality
M20 and Ø35 mm dual pole sockets
Optional Speaker Wheels (SPW-1) and Speaker Cover (SPCVR-DXS183)

Powered Subwoofer, Band-pass
32 Hz - 120 Hz
134 dB SPL
Diameter: 18" cone, Voice Coil: 4"
Class-D
Peak 2500 W
RMS 1250 W
32 bit/96 kHz Sampling
D-Remote (iOS/Android app)
Plywood
Φ35 mm (Depth 80 mm), M20 (Threaded depth 25 mm)
563 x 683 x 721 mm
51 kg
