dB Technologies Opera Reevo 212

The OPERA REEVO 212 offers exceptional sound pressure levels, impressive low-end extension, and a compact design ideal for anyone seeking high-quality sound. Its quasi 3-way configuration delivers powerful and clear audio, inspired by dBTechnologies' touring series, making it a standout in its category.

The coaxial design ensures impeccable sound reproduction, particularly in the midrange, enhancing separation and clarity. Features like the integrated HF horn and phase plug improve efficiency and transient response, while low-noise reflex ports minimize wind turbulence.

Powered by a Class-D Digipro G2 amplifier with 1050 W RMS and 2100 W Peak power, the REEVO 212 utilizes advanced DSP processing for coherent audio performance. It also includes factory-tailored voicing presets for various applications, from stage monitoring to full-range PA systems.

Technical Data

Speaker Type: Quasi 3-Way Active Speaker
Frequency Response: [-10dB] 48 - 20000 Hz
Max SPL: 133 dB
HF: 1" Exit CD, 1.75" v.c.
Type HF: Compression driver
Horizontal Directivity: 100°
Vertical Directivity: 80°
Horn: Asymmetrical Horn
LF: 2x 12" Neo, 2.5" v.c.
Amp Technology: Digipro G2 with SMPS
Amp Class: Class D
RMS Power: 1050 W (525W + 525W)
Peak Power: 2100 W (1050W + 1050W)
Controller: DSP 28/56 bit
AD/DA Converter: 24 bit/48 KHz
CrossOver Frequency: 1260 Hz
Signal Input: 1x Combo (XLR/Jack 6.3 mm) Line
Signal Output: 1x XLR Male (True link)
Controls: Gain (rotary)
Preset: (Flat, Playback, Wedge)
Housing: Polypropylene
Grille: Full grille
Handles: 1 on left Side, 1 on Top
Rigging Points: 2x M10 on Top + 1x M10 on Back
Pole Mount: 36 mm
Width: 345 mm
Height: 690 mm
Depth: 376 mm
Weight: 20,4 kg
