Yuer YF-40 Ten Band EQ

Yuer YF-40 Ten Band EQ – 10-Band Equalizer Effects Pedal

Yuer YF-40 Ten Band EQ is a 10-band equalizer effects pedal with ten frequency bandsranging from 31.25 Hz to 16 kHz. Each band provides ±12 dB boost/cut, while the pedal features illuminated sliders, level control and True Bypass.

Features
10-band equalizer
10 frequency bands from 31.25 Hz to 16 kHz
±12 dB boost/cut for each frequency band
Illuminated sliders
Level control
Status LED
True Bypass
Aluminum housing
6.3 mm mono jack input/output

Power Supply
Power supply via optional 9 V DC adapter
2.1 x 5.5 mm barrel plug
Polarity: center negative
Current draw: 30 mA
Battery operation not supported

Specifications
Type: 10-band equalizer effects pedal
Frequency range: 31.25 Hz–16 kHz
Boost/cut: ±12 dB per band
Connections: 6.3 mm mono jack input/output
Power supply: 9 V DC adapter, optional
Current draw: 30 mA
Dimensions (L x W x H): 108 x 69 x 51 mm
Weight: 290 g
