Yamaha CXR12 MK3

The CXR12 mk3 is a two-way loudspeaker that strikes the perfect balance between size and performance, offering exceptional clarity, precision, and powerful output. Ideal as a main speaker (FOH), for floor monitoring, or even as a side fill on stage—the CXR12 mk3 is an excellent choice for a wide range of sound needs.

12-inch LF + 1.75-inch HF Yamaha proprietary high-rigidity speaker units
The large-diameter horn ensures control over dispersion across a wide frequency range
Optimized port placement reduces the effects of standing waves
Lightweight, high-performance injection-molded enclosure with a symmetrical and functional design
The optional U-bracket UB-DXRDHR12A enables both vertical and horizontal use
The optional SPCVR-DXR123 speaker cover protects the speakers from damage during transport, long-term storage, or outdoor performances
Mounting points for use with eye bolts
Dual-angle stand sockets offer downward tilt at either 0° or -7°

2-way Speaker, Bass-reflex
51 Hz - 20 kHz
H90° x V60°
Crossover 1.8 kHz
124 dB SPL
LF: Diameter: Diameter: 12" cone, Voice Coil: 2.5"
HF: Diaphragm: 1.75“, Type: 1” throat compression driver
Peak 1100 W
Plastic (PP)
366 x 600 x 350 mm
15.4 kg
