Warm Audio WA-DI-A2 Active Stereo DI Box

Warm Audio WA-DI-A2 – Active Stereo DI Box with CineMag Transformers

The Warm Audio WA-DI-A2 is a two-channel active stereo DI box designed to connect keyboards, synthesizers, pedalboards, and other stereo devices to professional audio systems. It converts instrument signals to balanced microphone level for direct connection to mixing consoles, mic preamps, audio interfaces, and PA systems.

Key Features

• Active stereo DI box with two channels
• Specially wound CineMag USA transformers
• Converts instrument signal to balanced microphone level
• Continuously variable pad per channel (-3 dB to -30 dB)
• Ground lift per channel for reduced hum and ground loops
• Active circuit with extra headroom for low output levels
• Powered by 48V phantom power
• Designed for stereo devices and complex signal paths
• Rugged and compact aluminum chassis
• Suitable for studio and live use

Specifications

General
Type: Active stereo DI box
Model: Warm Audio WA-DI-A2
Number of channels: 2

Signal & Performance
Transformers: Custom CineMag USA output transformers
Function: Instrument signal to balanced microphone level
Frequency response: 10 Hz – 100 kHz (±0.5 dB)
THD: <0.003% (50 Hz – 20 kHz)

Controls & Features
Pad: Continuously variable, -3 dB to -30 dB
Ground lift: Yes, per channel

Impedance & Levels
Input impedance: 1 MΩ
Output impedance: 600 Ω
Output level: Mic level

Power Supply
48V phantom power

Construction
Chassis: Aluminum

Other
Warranty: 5 years

The Warm Audio WA-DI-A2 offers balanced, noise-free signal transmission with extra headroom and flexibility for both studio and live applications.
