Soundcraft Signature Plus 32

Soundcraft Signature Plus 32 – 32-Channel Analog Mixer with Lexicon Effects

The Soundcraft Signature Plus 32 is a 32-channel analog mixer designed with professional workflows and features for studio, live sound and streaming. It combines Soundcraft Ghost mic preamps, Sapphyre EQ, built-in dbx compressors and a Lexicon hardware effects processor with an intuitive layout and extensive connectivity and monitoring options.

Features
Soundcraft Ghost mic preamps with smooth high-gain behavior and rich harmoniccharacter
Sapphyre EQ for musical tone shaping
Built-in dbx one-knob compressors with harmonic enhancement
TRS insert points for flexible sound shaping and external processors
Lexicon hardware effects processor with Store and Tap Tempo
32 input channels for professional console workflows
Color-coded buttons and tactile “squircle” knobs for fast and precise navigation
Premium-quality faders for precise control
Extensive SSM (Simple Success Metering) for visual feedback across all inputs andoutputs
Listen bus for monitoring channels without interrupting the main mix
Talkback To routing for talkback to selected outputs
4 Aux sends and Mix to Auxes for flexible monitoring
User-configurable monitoring with independent headphone and control room outputs
Mute, Dim and Mono Sum monitoring functions
Selection from Auxes, Listen, Mix or direct USB returns for monitoring
4x4 USB-C interface supporting up to 192 kHz for recording and playback with laptops or mobile devices
USB inputs can be routed to channel strips or used to override the mix for break musicand DJ sets
Single press select for direct headphone and control room listening between sessions
Front-panel QR code providing access to training, manuals and support
Included software bundle supporting modern hybrid workflows
Rack-ear mounts included

Technical Specifications
Equivalent Input Noise (EIN): -128 dBu, A-weighted, AES17 filter (20 kHz), preamp gain 65 dB
Frequency Response: 20 Hz–20 kHz, +0.5/-1.5 dB relative to 1 kHz
Frequency Response, -3 dB: 15 Hz–80 kHz
Residual Noise: -90 dBu, A-weighted
Residual Noise, Signature Plus 32: -88 dBu, A-weighted
Residual Noise, RCA Channel: -78 dBu, A-weighted
THD+N: <0.005%
CMRR: >80 dB
Crosstalk: -80 dB
Aux Send Isolation: -75 dB

USB Specifications
Sample Rates: 44.1 kHz, 48 kHz, 88.1 kHz, 96 kHz, 176.2 kHz, 196 kHz
Full Scale Playback Level: +17 dBu
Full Scale Recording Level: +20 dBu
Dynamic Range, Playback: 94 dB
Dynamic Range, Recording: 107 dB
THD+N, Playback: <0.01%
THD+N, Recording: <0.005%

Dimensions and Weight
Product Dimensions: 806 × 535 × 106 mm
Weight, bare product: 13.9 kg
Box Dimensions: 974 × 655 × 213 mm
Weight, in box with accessories: 20.5 kg
Power Supply: Worldwide
