Solid State Logic SSL1

The SSL 1 is a compact 2-in/2-out USB-C audio interface that brings the renowned sound quality of Solid State Logic to musicians, producers, content creators, and streamers. Combining portability with professional performance, it delivers studio-grade recording and monitoring wherever you work.

Featuring an SSL-designed microphone preamp with up to 63 dB of gain, +48V phantom power, a high-pass filter, and Legacy 4K Analogue Enhancement, SSL 1 captures vocals and instruments with exceptional clarity, detail, and character. The dedicated instrument/line input is ideal for guitars, basses, synthesizers, drum machines, and other line-level sources.

Next-generation 32-bit / 192 kHz converters ensure outstanding audio quality with impressive dynamic range and low-noise performance. Balanced monitor outputs, a high-current headphone amplifier, and low-latency monitoring provide an accurate and inspiring recording experience.

Designed for modern workflows, SSL 1 supports Mac, Windows, and iOS devices, offers three stereo loopback channels for streaming and content creation, and features DC-coupled outputs for sending CV signals to compatible synthesizers and modular systems.

The included SSL Production Pack provides a comprehensive collection of software instruments, plug-ins, samples, and creative tools from leading audio developers, making SSL 1 a complete hardware and software production solution.

Features
2-In / 2-Out USB-C Audio Interface
SSL Designed Microphone Preamp
Legacy 4K Analogue Enhancement
+48V Phantom Power
High Pass Filter
Instrument DI And Line Input
32-Bit / 192 kHz Converters
Balanced Monitor Outputs
High-Current Headphone Output
Low-Latency Monitoring
Three Stereo Loopback Channels
DC-Coupled Outputs For CV Control
USB Bus Powered Or External 5V Power
Includes SSL Production Pack Software Bundle

Compatibility
Mac OS 12 And Above
Windows 11
Windows 11 ARM
iOS Devices
USB Audio Class 2.0 Mobile Devices

Specifications
Connectivity: USB 2.0 Type-C
Microphone Preamp Gain Range: 63 dB
Mic Preamp EIN: -130.5 dBu A-Weighted
Mic Preamp Dynamic Range: 113 dB A-Weighted
Instrument Input Dynamic Range: 114 dB A-Weighted
Max Instrument Input Level: +14 dBu
Line Input Dynamic Range: 114 dB A-Weighted
Max Line Input Level: +24.5 dBu
Balanced Output Dynamic Range: 116 dB
Max Output Level: +14 dBu
Headphone Dynamic Range: 116 dB A-Weighted
Max Headphone Output: +11 dBu
Converter Resolution: 32-Bit / 192 kHz
