Shanling CT-90 Black

The Shanling CT90 is a dedicated Hi-Fi CD transport designed for pure digital playback. It combines the SAA7824 servo system with a DA11 laser head, a top-loading mechanism with a matched CD puck, and a linear power supply with a 35 W transformer for stable and precise disc reading.

The CT90 offers extensive digital connectivity, including I²S, dual AES/EBU, coaxial SPDIF, and Shanling-specific USB audio output. Its FPGA provides 10 selectable I²S output modes to improve compatibility with third-party DACs, while a dedicated CT7302 upsampling circuit supports PCM and DSD conversion through I²S, AES, and coaxial outputs.

In addition to CD, CD-R and CD-RW playback, the CT90 supports USB storage devices with high-resolution audio up to PCM 768 kHz/32 bit and DSD512. USB playback can be controlled using the Eddict Player app, while Bluetooth input supports LDAC, aptX HD, aptX, AAC and SBC.

The CT90 features a robust aluminum chassis, a 4.8-inch widescreen display and a hinged top-loading CD cover. Its Pure CD Mode provides a simplified CD playback experience by disabling the remote, app communication, SRC upsampling, USB and Bluetooth modes, while turning off the screen after five seconds.

Features
Dedicated Hi-Fi CD transport for pure digital playback
SAA7824 servo system with DA11 laser head
Top-loading CD mechanism with matched CD puck
MOA-CD support with three selectable output modes
Dedicated CT7302 upsampling circuit
FPGA-based I²S output with 10 selectable modes
Dual AES/EBU digital outputs
Coaxial SPDIF digital output
Shanling-specific USB audio output
USB drive playback up to PCM 768 kHz/32 bit and DSD512
Bluetooth 5.0 input with LDAC, aptX HD, aptX, AAC and SBC
Eddict Player app control for Android and iOS
35 W linear power supply with transformer
External master clock input supporting 44.1 kHz / 10 MHz
Pure CD Mode for simplified CD playback
4.8-inch widescreen display
Aluminum chassis
No Wi-Fi connectivity

Compatibility
CD
CD-R
CD-RW
USB storage devices up to 2 TB recommended

Specifications
CD System: SAA7824 servo + DA11 head
Bluetooth Input: BT 5.0 (LDAC, aptX HD, aptX, AAC, SBC)
USB Output: PCM 768 kHz / 32 bit, DSD512 (without upsampling)
I²S Output: PCM 768 kHz / 32 bit, DSD512
AES/Coaxial Output: PCM 192 kHz / 32 bit, DSD64
USB Drive Audio Support: PCM, DSD, DXD, MQA, ISO, FLAC, WAV, AIFF, APE, AAC, MP3, OGG, ALAC, OPUS, M3U
External Clock Input: 44.1 kHz / 10 MHz

In The Box
1 x Shanling CT90
User manual

Dimensions & Weight
Dimensions: 28 × 23 × 9.1 cm
Weight: 3.5 kg
