Redshow Octo LED

Redshow Octo – Multifunctional LED Lighting Effect with Laser

The Redshow Octo is a multifunctional lighting effect that combines RGBW LEDs, rotating light arms, white LED effects, red and green lasers, a strobe and colored LED rings in one unit. Its dynamic pan and rotation effects create varied light shows for DJ performances, nightclubs, clubs, venues and other indoor events. The fixture supports DMX512 control as well as automatic programs, sound activation and master/slave operation.

Features and Functions

8 × 10 W RGBW CREE LEDs
4 × 10 W BEE RGBW CREE LEDs
3 × 5 W white LEDs for focused lighting effects
40 × 0.2 W 5050 LEDs for colored ring and animation effects
100 mW red laser and 100 mW green laser
Eight moving arms divided into two groups
Individual rotation of the arm groups with movement up to 100°
Pan movement up to 540°
Center effect with movement up to 180° and continuous forward and reverse rotation
Linear dimming from 0 to 100%
Built-in strobe with a maximum frequency of 20 Hz
26-channel DMX512 control
DMX control of RGBW colors, lasers, strobe, movement and LED ring effects
8 automatic programs
2 sound-activated modes with built-in microphone
Adjustable microphone sensitivity from 0 to 100
Master/slave function for synchronized operation of multiple fixtures
Included remote control for programs, effects and settings
Digital display for DMX address, programs, speed and basic settings
Cooling system with aluminum heatsink and fan
Designed for indoor use

Specifications

Primary LED light sources: 8 × 10 W RGBW CREE LEDs
Additional LED light sources: 4 × 10 W BEE RGBW CREE LEDs
White LED light sources: 3 × 5 W
Additional LED light sources: 40 × 0.2 W 5050 LEDs
Red laser: 100 mW
Green laser: 100 mW
Pan movement: Up to 540°
Moving arms: 2 groups, up to 100°
Center rotation: Up to 180° plus continuous rotation
Dimming: Linear, 0–100%
Strobe frequency: Up to 20 Hz
DMX channels: 26
Control modes: DMX512, auto, sound activation and master/slave
Automatic programs: 8
Sound-activated modes: 2
Remote control: Included
Power consumption: 150 W
Operating voltage: AC 95–245 V, 50 Hz
Cooling: Aluminum heatsink and fan
Application: Indoor use only
