HK Audio Elements MK2 110 Sub A

The HK Audio ELEMENTS MK2 110 Sub A is a compact active 10-inch subwoofer with 900 W RMS amplification, integrated DSP, and network connectivity. It forms the low-frequency foundation of the ELEMENTS MK2 Smart Base column PA system, providing powerful bass in a modular and scalable sound reinforcement setup.

The ELEMENTS MK2 system combines the 110 Sub A or 115 Sub A active subwoofer with ELEMENTS MK2 635 column modules and SPACER elements. The modular design supports configurations with up to three mid/high-frequency modules and two subwoofers, depending on the application and sound reinforcement requirements.

Automatic detection identifies the number of connected mid/high-frequency modules and adjusts the midrange response to suit the configuration. HK Audio SnapLock provides tool-free mechanical and audio connections, allowing components to be assembled quickly without additional tools.

The system supports network connections via RJ45 input and output on the subwoofer. It can also be combined with the LINEAR 5 MK2 115 Sub A low-frequency extension, and cardioid configurations are possible when using compatible subwoofers.

Features
Compact Active 10-Inch Subwoofer
900 W RMS Amplifier Power
1800 W Peak Amplifier Power
Integrated DSP
RJ45 Network Input And Output
Modular ELEMENTS MK2 Smart Base System Design
Automatic Detection Of Connected Mid/High-Frequency Modules
Automatic Midrange Response Compensation
Tool-Free HK Audio SnapLock Connections
Compatible With LINEAR 5 MK2 115 Sub A Low-Frequency Extension
Cardioid Configurations With Compatible Subwoofers

Specifications
Type: Active Subwoofer With DSP
Woofer: 1 × 10-Inch
Amplifier Power: 900 W RMS
Peak Amplifier Power: 1800 W
Maximum SPL: 123 dB
Frequency Response (-6 dB): 52 Hz To Crossover Frequency
Frequency Response (-10 dB): 49 Hz To Crossover Frequency
Network Connections: RJ45 Input And Output

Dimensions & Weight
Dimensions (W × H × D): 32.8 × 67.3 × 48.6 cm
Weight: 28.5 kg
