CME MIDI Thru5 WC

The MIDI Thru5 WC is a compact 1-in/5-out MIDI Thru box designed to distribute MIDI signals with high precision and reliable performance. It provides a simple wired MIDI solution out of the box, with optional Bluetooth MIDI expansion available via WIDI Core.

Built for clean and accurate MIDI routing, the MIDI Thru5 WC supports all standard MIDI messages including notes, controllers, clock, SysEx, timecode and MPE. Its high-speed optocoupler and close-to-zero latency wired transmission help ensure stable synchronization across connected devices.

The unit features one 5-pin MIDI input and five 5-pin MIDI Thru outputs, making it suitable for compact MIDI setups and multi-device rigs. USB-C power makes it easy to run from a standard USB charger, power bank or USB hub.

When fitted with the optional WIDI Core expansion, the MIDI Thru5 WC gains Bluetooth MIDI support with ultra-low latency wireless operation. This adds flexible hybrid connectivity for modern studio and live MIDI workflows.

Features
1-In/5-Out MIDI Thru Box
Optional Bluetooth MIDI Expansion
High-Speed Optocoupler
USB-C Powered
Supports All Standard MIDI Messages

Compatibility
Devices With Standard MIDI Sockets
WIDI Core Optional Bluetooth MIDI Expansion
macOS
iOS
Windows
Android

Specifications
MIDI Connectors: 1 x 5-Pin MIDI Input, 5 x 5-Pin MIDI Through
LED Indicators: 2
Power Supply: USB-C, 5V USB Bus
Power Consumption: 20 mW
Wired Transmission: Close To Zero Latency And Jitter
Bluetooth Technology: Bluetooth 5 BLE MIDI With Optional WIDI Core
Wireless Latency: As Low As 3 ms
Wireless Range: 20 m

Dimensions & Weight
Dimensions: 83.5 × 65 × 33.6 mm
Weight: 96 g
