Cayin HA-6 MK2 Black

The Cayin HA-6A MK2 is a premium single-ended Class A vacuum tube headphone amplifier featuring a redesigned dual-chassis architecture for improved isolation, lower noise, and enhanced sonic performance. Building upon the success of its predecessor, the MK2 introduces upgraded circuitry, a dedicated preamplifier output, and carefully selected vacuum tubes to deliver exceptional musicality and refinement.

The amplifier utilizes a fully tube-based design with JJ 12AU7/ECC82 driver tubes, matched Genalex Gold Lion KT88 output tubes, and dual JJ GZ34/5AR4 rectifier tubes. Operating in pure single-ended Class A, the HA-6A MK2 is engineered to preserve tonal richness, harmonic complexity, and natural musical flow.

Its dual-chassis construction separates the power supply from the amplification circuitry, reducing interference and creating a quieter background. A custom silver-plated copper umbilical cable connects the two units, ensuring efficient and stable power delivery.

The HA-6A MK2 offers selectable Triode and Ultralinear operating modes. Triode mode delivers a smooth, spacious presentation with rich harmonic texture, while Ultralinear mode enhances dynamics, extension, and overall drive capability.

Designed to accommodate a wide variety of headphones, the amplifier features impedance-matched outputs optimized for low, medium, and high-impedance loads. Outputs include 6.35 mm single-ended, 4.4 mm balanced, and 4-pin XLR balanced connections. The optimized 4.4 mm output also provides improved performance with sensitive in-ear monitors.

Beyond headphone listening, the dedicated PRE-OUT output enables integration with external power amplifiers or active speakers, allowing the HA-6A MK2 to function as the centerpiece of a high-end desktop or compact Hi-Fi system.

Premium internal components include custom-designed transformers, AudioCapX coupling capacitors, Japanese high-grade electrolytic capacitors, and a precision Japanese ALPS volume potentiometer. A built-in 60-second soft-start function protects the tubes and ensures stable operation before playback begins.

Features
Single-Ended Class A Vacuum Tube Headphone Amplifier
Dual-Chassis Design
Dedicated External Power Supply
Matched Genalex Gold Lion KT88 Output Tubes
JJ 12AU7/ECC82 Driver Tubes
JJ GZ34 / 5AR4 Rectifier Tubes
Triode And Ultralinear Operating Modes
Impedance-Matched Headphone Outputs
6.35 mm, 4.4 mm And 4-Pin XLR Outputs
Dedicated PRE-OUT Output
Custom In-House Transformers
AudioCapX Coupling Capacitors
Japanese ALPS Volume Control
60-Second Soft Start Function

Specifications
Amplifier Type: Single-Ended Class A Tube Headphone Amplifier
Output Tubes: 2 × Genalex Gold Lion KT88
Driver Tubes: 2 × JJ 12AU7 / ECC82
Rectifier Tubes: 2 × JJ GZ34 / 5AR4
Output Power (Triode Mode): 3000mW Per Channel
Output Power (Ultralinear Mode): 4500mW Per Channel
Headphone Outputs: 6.35 mm, 4.4 mm Balanced, 4-Pin XLR Balanced
Load Matching: Low 8–64Ω, Mid 65–250Ω, High 251–600Ω
Volume Control: Japanese ALPS Potentiometer
Additional Output: PRE-OUT
Soft Start Delay: 60 Seconds

Dimensions & Weight
Power Supply: 160 × 297 × 185 mm
Amplifier: 285 × 297 × 185 mm
Power Supply Weight: 8.2 kg
Amplifier Weight: 11.2 kg
Total Weight: 19.4 kg

In The Box
Cayin HA-6A MK2 Amplifier
External Power Supply
Vacuum Tubes
Power Cable
User Manual
