Audac CAP248

The Audac CAP248 is a 2-channel 100V amplifier rated at 2 x 480W, designed for larger applications or zone solutions with multiple speakers. The CAP248 features balanced inputs and a switchable high-pass filter (400 Hz) for each channel.

Class D amplifiers and a switched-mode power supply provide high efficiency and low weight. Protection circuits for short circuit, clipping, DC, and overload. Each channel has separate gain control and a signal feed-through, e.g., to additional power amplifiers or the next channel.

- 2 x 480W / 100V
- Gain / channel (rear panel)
- Disengageable high-pass filter / channel
- Signal pass-through
- Balanced inputs
- On the front panel, 3 LEDs per channel indicate the status of the output signal (Sig, -20dB, Clip)
- Mounting depth: 420mm
