American DJ Focus Wash 400

The FOCUS WASH 400 is a 400W, RGBACL (Red, Green, Blue, Amber, Cyan and Lime), LED moving light wash, 10 to 46-degree motorized zoom, 16-bit pan / tilt movement, RGBACL color mixing, variable dimming modes / curves and strobe effects, DMX and RDM (remote device management) protocol support, DMX and power in/out connections, LCD menu display with 6 button control panel, multiple unit power linking, flicker free operation for TV and FILM, and a multi-voltage universal auto switching power supply (AC100-240V).

Specifications

Source

• Source: RGBACL LED Engine

• Individual LED wattage : 400W

• Average lifetime: approximately 50,000 hrs



Optics

• Beam Angle: 10 - 46 degrees

• Fresnel Lens

• Motorized Zoom



Control

• DMX-512 Protocol

• 3 DMX Channel Modes

• RDM compatible (Remote Device management)

• 16bit dimming 0-100%

• 6 Dimming Modes: Standard, Stage, TV, Architectural, Theatre, Stage 2

• 4 Dimming Curves : Linear / Square / Inverse Square / S-Curve

• Various strobe effects

• LCD Menu Display with 6-button Control

• 3 Fan settings : Auto, High and Low Noise



Colors

• RGBACL Color Mixing (Red, Green, Blue, Amber, Cyan, Lime)

• CRI: 91

• Preset Color Temperatures (2700k, 3200k, 4000k, 5600k and 6500k)



Construction

• Plastic housing



Electrical

• Multivoltage : 100-240V 50/60Hz

• Power Draw : 438W



Connections

• Locking 3- & 5-pin DMX In/Out

• IP65 Locking Power In/Out



Dimensions & Weight:

• Dimensions: 279 x 238 x 447mm

• Weight: 10,7 kg.
